ARESWIN stocks Individual linear motion guide blocks from the THK LM guide SSR series for quick and easy interchangeability, ensuring problem free maintenance and short down times.
[Features]
•Caged ball design provided high-speed rotation, a low noise level, and extended service life.
•Balls travel in four precision-ground raceways on an LM rail through the LM block, and endplates incorporated in the LM block.
•Each row of balls is placed at a contact angle of 45°so that the rated loads applied to the LM block are uniform in all four directions (radial, reverse-radial and lateral directions) for a constant low friction coefficient, and increased rigidity.
E-mail us for THK discounts and expedited delivery ✉
THK SSR-XTB Guide
THK SSR-XTB Linear Guide with the flange of the LM block has through holes.Used in places where the table cannot have through holes for mounting bolts. THK SSR linar guide rail is long-term maintenance free and high accuracy. THK SSR-XTB Guide way is self-adjusting capability.
THK SSR-XTB guide rails can be customized according to customer’s length requirements.
THK SSR-XTB Block is flange type,this type THK linear guide with Bolts mounted from below.
Basic load rating (kN): Basic dynamic load rating 14.7 to 64.6 / Basic static load rating 16.5 to 71.6
Size : 15,20,25,30,35
Model NO : SSR 15XTB, SSR 20XTB, SSR 25XTB,SSR 30XTB,SSR 35XTB
THK LM guides are designed to withstand heavy loads and provide long service life. The precision-ground raceways and balls ensure smooth and accurate movement, reducing friction and wear. This results in extended operating life and reduced downtime for maintenance.
